1.54 inch TFT display MIPI interface 320x320 pixel square LCD

  • 2 - 9999 Pieces
    $9.00
  • >=10000 Pieces
    $3.90
Type:
TFT
Supplier Type:
Original manufacturer odm
Lead Time:
Quantity(Pieces) 1 - 1000 1001 - 5000 5001 - 10000 >10000
Est. Time(days) 35 45 50 Negotiable
Customization:
Customized logo (Min. Order: 2000 Pieces)
FPC (Min. Order: 2000 Pieces)

More

Interface (Min. Order: 2000 Pieces)
Brightness (Min. Order: 2000 Pieces)
Touch Panel (Min. Order: 2000 Pieces) Less
Samples:
$9.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Display Size:
1.54 Inch
Place of Origin:
Guangdong, China
Model Number:
KWH0154DF04-F01
Brand Name:
Formike
Product Name:
1.54 inch MIPI TFT display square LCD
Resolution:
320 x RGB x 320
Type:
TFT
Outline dimession:
31.5 x 35.0 x 2.3mm
Active Area:
27.72 x 27.72mm
Interface:
MIPI
Luminance(cd/m2):
400
Viewing Angle:
12 O'clock(Gray inversion)
Surface Treatment:
Anti-Glare
IC Driver:
ST7789H2
Product Certification certification
CE Certified.
SGS Certified.
Supply Ability
Supply Ability:
900000 Piece/Pieces per Month custom 1.54 inch MIPI TFT display square LCD
Packaging & Delivery
Packaging Details
1.54 inch TFT display MIPI interface 320x320 pixel square LCD:
Standard Package.
Port
HongKong
Lead Time :
Quantity(Pieces) 1 - 1000 1001 - 5000 5001 - 10000 >10000
Est. Time(days) 35 45 50 To be negotiated

1.54 inch TFT display MIPI interface 320x320 pixel square LCD

LCD Name 1.54 inch TFT display MIPI interface 320x320 pixel square LCD

LCD Size

1.54 inch

Resolution

320 x RGB x 320

Color

262K

Brightness

400cd/m2

Outline Dimension

31.5 x 35.0 x 2.3mm

Active Area(HxV mm)

27.72(H) x 27.72(V)mm

Viewing Direction

12 O’clock(Gray inversion)

Interface

MIPI

Pixel Arrangement

RGB Stripe

Surface Treatment

Anti-Glare

IC Driver

ST7789H2

Backlight

3PCS LEDS



* KWH0154DF04-F01 is a color active matrix square LCD module incorporating amorphous silicon TFT (Thin Film Transistor).

It iscomposed of a color TFT-LCD panel, driver IC, FPC and a back light unit.

The module display area contains 320x320 pixels and can display up to 262K colors.





Formike Group was founded in 1999, which engaged in R&D, design, manufacture and sales of LCD display and accessories parts as well as Wi-Fi modules. With the rapid development of global digital industry, LCD becomes the main role of information display. On the other hand, smart era has come, the Wi-Fi modules will be used in various fields along with internet. Formike Group devote ourselves to meet public demand, invest tangible and intangible assets to scale up and strengthen, introduce talents and capital, expand marketing channel, make business scope spread to global market and bring LCD display, Wi-Fi modules and integrated solutions to people's life, hope to realize intelligent home, improve the quality of life and provide the better visual treat.





Q: What is the MOQ?
A: Generally if you choose the different products, our minimum order qty also will be different.
1.54 inch TFT display MIPI interface 320x320 pixel square LCD

Q: What about the delivery time?
 A: The LCD products need 5-6 weeks to be made after receive deposit.


 Q: Does your product have any warranty?
  A: Yes, we offer 12 months warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.

Q: What's your payment method?
 A: We usually accept the payment methods include T/T, Western Union and Trade Assurance.  50-100% deposit in advance and balance before shipping upon the payment amount. Buyer can choose which payment ways that you accept.

Q:  What's your shipping method?
A: We provide comprehensive shipping methods.
    For small quantity orders we ship by UPS Air-Express,or DHL/FEDEX/TNT/EMS Express service, it is safe and fast.
    For large quantity orders we ship by buyer's cargo agent in China, we can also ship by Air transportation or sea  transportation.

Q: Do you offer custom solution?
A:  Yes,we can offer custom solution if standard products couldn't meet buyer' requirements.



Q: How to Contact us?

A: Send your Inquiry Details in the Below, Click "Send" Now!
